Integrated Bottom-Air-Supply High-Temperature Anti-Corrosion Air Conditioner

The unit is equipped with compressors from renowned international brands—such as Daikin, Panasonic, or Mitsubishi—which offer advantages such as high volumetric efficiency, strong vibration resistance, and a compact footprint.
Featuring a top-mounted configuration with bottom air discharge, the unit occupies no indoor space; it presents an aesthetically pleasing and elegant appearance while being more compact in size than comparable products.
Its unique design incorporates dust removal capabilities and requires minimal maintenance.
The fan features Class F insulation, is rated for temperatures up to 130°C, and operates with low noise and high vibration resistance.
The heat exchanger utilizes high-efficiency heat transfer tubes to ensure superior thermal performance, while the evaporator fins are treated with a hydrophilic coating.
The system is equipped with high- and low-pressure protection mechanisms, and each motor is safeguarded by independent overload and thermal protection.
Operation is simple and user-friendly.

Model	OTD (R)-40
Cooling Capacity	5000w
Heating Capacity	4000w
Cooling Power Consumption	3600w
Heating Power Consumption	3800w
Power Supply	Three Phase: AC380~415V/50Hz
Air Supply Method	Bottom Air Supply
Indoor Airflow Volume	1200m³/h
Refrigerant	R142b
Refrigerant volume	1700g
Weight	170Kg
Dimensions (L × W × H)	1250×798×550mm
Remarks:	Outdoor dry-bulb temperature: 55°C; Indoor dry-bulb temperature: 30°C; Indoor wet-bulb temperature: 24°C.
