Power Supply: AC220V × (80–110%), 50Hz
Operating Environment (Controller): –25°C to 65°C; relative humidity ≤95%RH
Activation Point: 85%RH ±5%RH (at 20°C)
Control Mode: Manual/automatic switching; one‑to‑one sensor‑based control
Response Time: Typical value ≤5 seconds
Output: Working voltage ×1; rated resistive load AC220V, 3A, normally open
Power Consumption: ≤1.8W
High‑Voltage Withstand: 50Hz, 2000Vrms for 3 minutes with no breakdown or flashover
Vibration Resistance: 10–5–10Hz, 2g, 3 minutes, normal operation
Insulation Resistance: ≥500MΩ
Three‑Proof Protection (TH): Resistant to gases containing acids, alkalis, and salts
Service Life: Load‑driving endurance ≥10⁸ operations
Dimensions: 48 × 48 × 78 mm³
